工业门


Industrial doors

GridScan/Pro SI

GridScan/Pro SI is a highly reliable SIL 2-certified safety light curtain with a serial interface for industrial doors. Certified with an EC-type examination, it can be used in any door. The serial interface allows for the integration of additional functions such as soft stop, increasing the door`s service life.

GridScan/Pro

GridScan/Pro是一款高度可靠的SIL 2认证的工业门安全光幕。通过了欧盟型式试验认证,可在任何门上使用。由于其多输出设计,GridScan/Pro可以集成在所有类型的门控制系统中。

GridScan/Mini

GridScan/Mini是一款外观小巧的安全等级为2级的光幕产品。其具有的门消隐功能使其可以被集成在门的设计中。配备有FSS输出的系统能在无测试信号的情况下满足EN 13849-1 2类的标准。

GridScan/Mini-SB2/-ST2

GridScan/Mini-SB2/-ST2是一款极其小巧的、通过了EC型式检测和SIL2认证的安全光幕。其具有的门消隐功能使其可以被集成在门的设计中。配备有FSS输出的系统能满足EN 13849-1 Cat. 2的标准,同时又无需测试。

RAYTECTOR RAY-S (pull-in protection)

The safety photo eye is used for entrapment protection on industrial doors, mainly for rolling grills. An interruption of the light beam initiates a signal between emitter and receiver which interrupts the movement of the power operated door. The pull-in protection RAYTECTOR is suitable for absolute fitting dimensions between 1.5 m to 10 m. Emitter and receiver are inserted in compound-filled plastic housings. The respective 10.5 m length of the connector cables allow the direct connection to the control unit.

RAY-RT

With its adaptable design, RAY-RT can be installed in the most challenging locations of door construction. It is designed for securing various points of the door and due to its compact size, it can even be integrated in the guide rail.

RAY-M

RAY-M was designed as a light barrier for a small mounting space. It generates the standard OSE signal and can be operated in combination with well known control units. The RAY-M DUO is a double beam light barrier for safeguarding of two parallel areas via one signal. Areas at two different heights, e.g. persons and trucks, can be monitored simultaneously with only one product (solution `D` acc. to EN 12453 possible).

RAY-N

RAY-N photo eyes are monitored sensors, using the same proven technology as the OPTOEYE. When the signal between emitter and receiver is interrupted, the sensor sends a signal to the operator to stop and reverse the door. These sensors are long range (13 m), yet are NEMA 1 rated for price-sensitive applications. Also, the versatility of threaded design allows for flush mounting (for example, within the guide of a rolling door) or mounting to a bracket for easy installation.

OPTOEYE OPE

The OPTOEYE consists of two infrared sensors inserted into flexible rubber brackets, which are mounted next to the door opening. Installation is very easy since the LEDs indicate alignment and power. The OPTOEYE is specifically designed to withstand rough commercial and industrial environments. Its flexible design makes it highly resistant to impacts and mechanical shocks; its NEMA4X rating proves its resistance against any kind of moisture.

easyray

easyray系列对射光电具有大光阑角度和固定孔,因此非常易于安装。该系列传感器具有响应速度快的特点,非常适用于对传感器要求快速响应时间的应用场合。

Rubber profiles

The hollow rubber profiles enclose the OSE safety light barrier. When the hollow rubber profile is deformed, the optical channel is interrupted, causing a dynamic safety signal to fail. This is detected by the control unit which interrupts the enable circuit. The potentially hazardous movement is halted.

Bumpers

Bumpers are used for long-term protection of horizontally mounted safety contact edges. In a closed state the door leaf sits on the bumpers. These protect the rubber profile and/or the inner optical closing edge device from damage. The installation height is selected to ensure that the hollow chamber containing the closing edge sensor is not deformed, but that the sealing flanges or the sealing chamber make tight contact with the floor.

Retainer

Most commercial doors are equipped with the proper retainer in order to install a rubber profile. For retro-fitting or door sections without the right retainer, VITECTOR by CEDES offers special retainers for installation of sensing edges.

Coil cords

Coil Cords are commonly used to wire the sensing edge from the moving door panel to the stationary door control unit. This solution is cost efficient and proven to work reliably. The wiring connection from the sensing edge to the coil cord is usually done within the protected environment of a junction box.

UPS - 通用电源

通用电源可为光幕提供24V电源,例如cegard/Mini。范围在20VAC到265VAC或20VDC到375VDC的电压均可被转换。光幕半导体输出端也可以被转换成无源继电器触点。

UPS Plus (通用电源)

通用电源UPS Plus配置有两个无源继电器输出端,可以同时连接两个光幕。输入电压范围从20VAC到265VAC或从20VDC到375VDC。

电源转换器

电源转换器可为传感器提供24V电源电压,例如cegard/Mini。范围从85VAC到265VAC的输入电压均可被转换。传感器的半导体输出也可以被转换为无源继电器触点。

Optical Sensing Edges (OSE, Cat.3)

Safety edges are used wherever moving edges pose a hazard to people. The hazardous areas are protected by hollow rubber profiles. As soon as a person or object touches them, the sensing profile is deformed, and the potentially hazardous movement stops.

Optical Sensing Edges (OSE, Cat.4)

Safety edges are used wherever moving edges pose a hazard to people. The hazardous areas are protected by hollow rubber profiles. As soon as a person or object touches them, the sensing profile is deformed, and the potentially hazardous movement stops.

Optical Sensing Edges (OSE, UL)

Safety edges are used wherever moving edges pose a hazard to people. The hazardous areas are protected by hollow rubber profiles. As soon as a person or object touches them, the sensing profile is deformed, and the potentially hazardous movement stops.

Airwave switch DW

Airwave switches are actuated by pressure waves created by any kind of pressure source. A rubber tube inside the weather seal of the door is used to create a pressure wave. When the pneumatic edge hits an obstacle, a pressure wave is created inside of the tube and this wave is recognized by the switch.

OPTOCHAIN

The OPTOCHAIN is a modular system of sensing edges for the use on automatic doors and machines. It is made up of one master sensing edge and up to four slave safety edges which are connected in series. The master is a low power version of the well-known OPTOEDGE. The slaves are characterized by a special transmitter and can process an incoming safety signal of a previous sensing edge.

OPTOGUARD OGD

The pre-traveling light barrier OPTOGUARD features two telescopic sledges, each of them carrying a pair of photocell-sensors. When touching the ground, the sledge is pushed into the plastic housing tensioning a spring. The shape of the housing forces the sensor arms to perform a 60° rotation when sliding in, eventually locating them in parallel alignment.

ENTRYSENSE (ENS)

Wicket doors in panels of power operated sectional doors must be locked safely in their closing position prior to any operation of the sectional door. This is applicable to fully automated doors as well as to doors in hold-to-run mode. A safe contact must prevent the entire door from moving while the wicket door is not fully closed. ENTRYSENSE is available in three versions to work with different door control units.
