GridScan/Pro SI

GridScan/Pro SI is a highly reliable SIL 2-certified safety light curtain with a serial interface for industrial doors. Certified with an EC-type examination, it can be used in any door. The serial interface allows for the integration of additional functions such as soft stop, increasing the door`s service life.

GridScan/Pro

GridScan/Pro is a highly reliable SIL 2-certified safety light curtain for industrial doors. Equipped with EC type examination certification, it can be used at any door. Thanks to its multi-output design and the changeable operating mode (from blanking to static), the GridScan/Pro can be integrated in all types of door control systems.

cegard/Mini-CC

The cegard/Mini-CC light curtain offers a major increase in the level of safeguarding of elevators doors thanks to its criss-cross beams, which remain active up to complete elevator door closure.

cegard/Mini-MOD

The cegard/Mini-MOD’s relay-output and universal power supply allows it to be efficiently integrated into any existing elevator facility, with no need for additional components.

easygard

CEDES easygard100 light curtains are designed in line with the latest elevator door requirements. The products are compliant with the EN81-20 code, offer an excellent performance, and meet highest quality expectations.

cegard/Mini

The cegard/Mini’s robust design is the key to its market-leading quality. This makes it the most cost-efficient solution for elevator door safeguarding.

GridScan/Mini-SR

The GridScan/Mini-SR is EN ISO 13849-1 certified and fulfils Safety Category 2 and Performance Level D without the need for a test by the elevator controller.

cegard/Max custom made

The cegard/Max custom made provides detection and safeguarding for various types of elevators. It can be fully customized in very low quantities to match a customerʼs needs.

cegard/Lift

The cegard/Lift greatly increases safeguarding for elevator cabs that do not have inner doors without significantly impacting on available floor space. Its intelligent mounting possibilities save space and allow quick, secure integration.

CEDES Elevate

CEDES Elevate is a cloud-based IoT platform that enables smart elevator management, optimizing service through data-driven maintenance recommendations, and people flow insights.

cegard/Smart ECom solution (data hub)

The cegard/Smart ECom solution bundles passenger safety with exceptional operational efficiency. It combines door safeguarding (compliant with EN 81:20 and A17.1-2019/-2022) with an elevator data hub connecting to our cloud-based IoT platform CEDES Elevate and enabling multimedia emergency communications.

cegard/Smart solution (stand-alone IoT)

The cegard/Smart solution provides door safeguarding (compliant with EN 81:20 and A17.1) and connects to our cloud-based IoT platform CEDES Elevate, allowing for 24/7 elevator health monitoring and people flow analysis.

cegard/Smart, A variant

The IoT-enabling smart light curtain is connected to our IoT Cloud platform CEDES Elevate to provide a complete IoT solution.

GridScan/Mini

The GridScan/Mini is an extremely compact SIL 2-certified safety light curtain. Its door blanking function allows it to be integrated into the door design. The system with an FSS output fulfills EN 13849-1 Cat. 2 without testing.

RAY-RT

With its adaptable design, RAY-RT can be installed in the most challenging locations of door construction. It is designed for securing various points of the door and due to its compact size, it can even be integrated in the guide rail.

RAYTECTOR RAY-S (pull-in protection)

The safety photo eye is used for entrapment protection on industrial doors, mainly for rolling grills. An interruption of the light beam initiates a signal between emitter and receiver which interrupts the movement of the power operated door.

RAY-M

RAY-M was designed as a light barrier for a small mounting space. It generates the standard OSE signal and can be operated in combination with well known control units. The RAY-M DUO is a double beam light barrier for safeguarding of two parallel areas via one signal.

RAY-N

RAY-N photo eyes are monitored sensors, using the same proven technology as the OPTOEYE. When the signal between emitter and receiver is interrupted, the sensor sends a signal to the operator to stop and reverse the door.

OPTOEYE OPE

The OPTOEYE consists of two infrared sensors inserted into flexible rubber brackets, which are mounted next to the door opening. Installation is very easy since the LEDs indicate alignment and power.

ELS 500

The ELS 500 light barrier has a very robust design and due to the M12 housing it is easy to mount. The emitter has an adjustable emitting strength to configure the system for the used application.

ELS 400

The ELS 400 light barrier has a very compact design and is ideal if the space on a door profile is limited. With an incredibly small width of only 11.6 mm, it fits perfectly into all standard door profiles.

ELS 300

The ELS 300 light barrier is certified under EN-13849, Category 2, Performance Level C. Its compact design allows it to be easily integrated into the safeguarding application.

ELS 263

The ELS 263 light barrier has a very compact design and is easily built into door frames or indeed anywhere where space is limited. Fully potted, it is also ideal for outdoor safeguarding applications.

easyray

The easyray light barrier product range is easy to mount due to the wide opening angle and the mounting holes in the sensor. With a fast response time the sensor is ideal for time critical applications.

Micro MF

The Micro MF is a universal light curtain for safeguarding automatic doors. Its robustness and flexible optical element arrangement allows it to be adapted to customer-specific applications.

RDS 100

The RDS 100 radar sensor provides very reliable door activation. The sensor can be used for all automatic doors, thanks to his large detection area of 4 x 2 m at a mounting height of 2.2 m.

IMS 100 Pro

The IMS 100 Pro provides a new level of safeguarding by monitoring the elevator entrance area. This reduces overall door-opening times and improves elevator efficiency.

TOF/Start

The TOF/Start detects people or objects approaching escalators, revolving and swing doors, industrial doors and personnel sluices. Cross-traffic is ignored, ensuring energy-efficient usage.

TPS 210

The TPS 210 is a direction-detection sensor based on triangulation technology. It can also be used for people-counting applications.

CabSafe™

The 2019 North American Elevator Safety Code (ANSI A17.1-2019 / CSA B44-19) defines new and clarifies existing requirements for the means of detecting persons or objects between the doors (2D) or approaching the elevator (3D). CEDES CabSafe™ system, consisting of a Controller, a 2D light curtain and a 3D TOF sensor, can fulfill all these code requirements and more.

TOFniva

The TOFniva monitors a area of up to 2 m x 2 m, detecting when people or objects enter it. The detection area can be set to meet specific application needs and works with all backgrounds.

TOF/Start-EA

The TOF/Start-EA is the ideal door-opening sensor for pedestrian and industrial doors. Cross-traffic is ignored, ensuring energy-efficient usage and reducing mechanical wear.

TOF/Spot

The TOF/Spot is a compact yet powerful measuring system with the widest range of application possibilities. It offers ultra-reliable detection and exact detection range setting.

APS

The APS is a contactless absolute positioning system for elevators. It supports speeds of up to 20 m/s and distances of up to 1,500 m. As SIL 3 rated, it can be used for safety-relevant functions.

APS C-Series one

The APS C-Series one is a contactless absolute positioning system for elevators. It supports speeds of up to 20 m/s and distances of up to 1,500 m.

iDiscovery

The iDiscovery is a powerful SIL 3 and EN 81-20/50 compliant safety supervisor unit. In conjunction with CEDES’ APS (Absolute Positioning System), it takes over safety-relevant functions of the elevator.

GLS 326

The GLS 326 slot-type light barrier features three infrared beams, each with its own output. Its integrated twin microprocessors make it possible to cost-effectively provide a variety of applications in combination with the elevator control system.

GLS 126 NT

The GLS 126 NT is a slot-type light barrier which provides millimeter-exact positioning of elevators. Fully sealed with an enclosure rating of IP66, its high light reserve guarantees protection against dirt, dust and smoke.

GLS 526

The GLS 526 slot-type light barrier features five infrared beams, each with its own output. This enables the GLS 526 to provide a variety of hoistway signals which allows for very cost-efficient solutions.

Cable sets (CS)

OSE cable sets contain a junction box, a spiral cable and cable gland accessories, and hence everything required to connect OSE sensors to a control device. Cable sets are provided with junction boxes and spiral cables in three sizes, each designed for different door types.

Coil cords

Coil cords are commonly used to wire the sensing edge from the moving door panel to the stationary door control unit. This solution is cost efficient and proven to work reliably. The wiring connection from the sensing edge to the coil cord is usually done within the protected environment of a junction box.

Rubber profiles

The hollow rubber profiles enclose the OSE safety light barrier. When the hollow rubber profile is deformed, the optical channel is interrupted, causing a dynamic safety signal to fail. This is detected by the control unit which interrupts the enable circuit. The potentially hazardous movement is halted.

Bumpers

Bumpers are used for long-term protection of horizontally mounted safety contact edges. In a closed state the door leaf sits on the bumpers. These protect the rubber proﬁle and/or the inner optical closing edge device from damage.

Retainer

Most commercial doors are equipped with the proper retainer in order to install a rubber profile. For retro-fitting or door sections without the right retainer, VITECTOR by CEDES offers special retainers for the installation of sensing edges.

Controller OSE-C

For retrofitting older door systems, or for door controls without an integrated "OSE" interface, control units are required for evaluating the signal. All safety light barriers with an OSE signal can be connected to the evaluation units.

Junction boxes (JB)

The junction boxes are available in different sizes (small, medium, large), depending on the desired application. The housing can be opaque or transparent – e.g. the status LED of the safety edge is visible through the translucent lid.

Airwave accessories

Various accessories are available for the airwave switches, such as end and connection plugs, signal hoses made of PVC or silicone and airhose connectors (straight, angled or t-shaped).

UPS

The Universal Power Supply (UPS) offers a 24 V power supply for sensors, e.g. cegard/Mini. Input voltages ranging from 20 to 265 VAC or 20 to 375 VDC can be converted. The sensor’s semiconductor output will also be converted to a potential-free relay contact.

Offset bracket (AC)

The mounting bracket is installed at half of the total height of the door, then wired up to the operator. This allows the coil cord to stretch only half the lenght.

UPS Plus

The Universal Power Supply UPS Plus has two potential-free relay outputs and enables the simultaneous connection of two sensors. Input voltages can range from 20 to 265 VAC or 20 to 375 VDC.

Power line converter

The power line converter offers a 24 V power supply for sensors, e.g. cegard/Mini. Input voltages ranging from 85 to 265 VAC can be converted. The sensor’s semiconductor output is also converted to a potential-free relay contact.

Relay module

Converts a sensor’s semiconductor output to potential-free relay contact.

Optical Sensing Edges (OSE, Cat.3)

Safety edges are used wherever moving edges pose a hazard to people. The hazardous areas are protected by hollow rubber profiles. As soon as a person or object touches them, the sensing profile is deformed, and the potentially hazardous movement stops.

Optical Sensing Edges (OSE, Cat.4)

Safety edges are used wherever moving edges pose a hazard to people. The hazardous areas are protected by hollow rubber profiles. As soon as a person or object touches them, the sensing profile is deformed, and the potentially hazardous movement stops.

Optical Sensing Edges (OSE, UL)

Safety edges are used wherever moving edges pose a hazard to people. The hazardous areas are protected by hollow rubber profiles. As soon as a person or object touches them, the sensing profile is deformed, and the potentially hazardous movement stops.

Airwave switch DW

Airwave switches are actuated by pressure waves created by any kind of pressure source. A rubber tube inside the weather seal of the door is used to create a pressure wave. When the pneumatic edge hits an obstacle, a pressure wave is created inside of the tube and this wave is recognized by the switch.

OPTOCHAIN

The OPTOCHAIN is a modular system of sensing edges for the use on automatic doors and machines. It is made up of one master sensing edge and up to four slave safety edges which are connected in series. The master is a low power version of the well-known OPTOEDGE.

OPTOGUARD OGD

The pre-traveling light barrier OPTOGUARD features two telescopic sledges, each of them carrying a pair of photocell-sensors. When touching the ground, the sledge is pushed into the plastic housing tensioning a spring. The shape of the housing forces the sensor arms to perform a 60° rotation when sliding in, eventually locating them in parallel alignment.

ENTRYSENSE (ENS)

Wicket doors in panels of power operated sectional doors must be locked safely in their closing position prior to any operation of the sectional door. This is applicable to fully automated doors as well as to doors in hold-to-run mode. A safe contact must prevent the entire door from moving while the wicket door is not fully closed.

EasyGate IP

The end of 2G and 3G networks is approaching. Transition seamlessly to modern 4G with the EasyGate IP. Connect an analogue elevator communicator to the gateway. This will ensure voice or data (VoIP) communication via a mobile network with an operations centre.
